Ecco 3.5 kVA Hybrid Solar Power Kit

• Inverter: Ecco ES3500, 3.5 kVA / 3,500 W
• Battery: 2.56 kWh LiFePO₄, 25.6 V, 100 Ah
• Solar Panels: 3 × 460 W monocrystalline
• Total PV Capacity: 1,380 W
• Output: 230 V AC
• Battery: Expandable
• MPPT: Up to 100 A
• Maximum PV Array: 4,000 W

Inverter dimensions: approximately 359 × 295 × 100 mm
Inverter weight: approximately 7 kg

Key Features

• 3.5kVA / 3500W Hybrid Inverter

• 2.56kWh LiFePO4 Battery Storage

• 3 x 460W Monocrystalline Solar Panels

• Pure Sine Wave Output

• Integrated MPPT Solar Charge Controller

• 100A Maximum MPPT Charge Current

• Expandable Battery Configuration

• Suitable for Backup and Solar Applications

System Components

• 1 x Ecco ES3500 Hybrid Inverter

• 2 x 12.8V 100Ah LiFePO4 Lithium Batteries

• 3 x 460W Monocrystalline Solar Panels

• User Documentation

Inverter Specifications

• Model: ES3500

• Rated Power: 3500VA / 3500W

• Nominal Battery Voltage: 24V

• AC Input: 230VAC, 50/60Hz

• AC Output: 230VAC

• Maximum AC Charge Current: 60A

• Maximum Combined Charge Current (AC + PV): 100A

• Maximum PV Array Power: 4000W

• MPPT Charge Current: 100A

• Minimum Solar Voltage: 30VDC

• Maximum PV Open Circuit Voltage: 500VDC

• Output Waveform: Pure Sine Wave

Battery Specifications

• Battery Type: LiFePO4 (Lithium Iron Phosphate)

• Capacity per Battery: 1.28kWh

• Total Battery Capacity: 2.56kWh

• Nominal Voltage: 12.8V

• Capacity: 100Ah

• Maximum Discharge Current: 100A

• Cycle Life: Up to 3000 Cycles at 80% DOD

• Series and Parallel Expansion Supported

• Operating Temperature (Charging): 0°C to 45°C

• Dimensions (Per Battery): 329 x 173 x 216mm

• 3 Years Warranty
